Introduction

This library implements the APIs required to communicate with Microchip Security device. The family of devices supported currently are:

The best place to start is with the Microchip Trust Platform

Online API documentation is at https://microchiptech.github.io/cryptoauthlib/

Latest software and examples can be found at:

Prerequisite hardware to run CryptoAuthLib examples:

CryptoAuth Trust Platform Development Kit

Alternatively a Microchip MCU and Adapter Board:

ATSAMR21 Xplained Pro or ATSAMD21 Xplained Pro
CryptoAuth Xplained Pro Extension or CryptoAuthentication SOIC Socket Board to accept SOIC parts

For most development, using socketed top-boards is preferable until your configuration is well tested, then you can commit it to a CryptoAuth Xplained Pro Extension, for example. Keep in mind that once you lock a device, it will not be changeable.

Examples

Watch CryptoAuthLib Documents for new examples coming online.
Node Authentication Example Using Asymmetric PKI is a complete, all-in-one example demonstrating all the stages of crypto authentication starting from provisioning the Crypto Authentication device ATECC608/ATECC508A with keys and certificates to demonstrating an authentication sequence using asymmetric techniques. http://www.microchip.com/SWLibraryWeb/product.aspx?product=CryptoAuthLib

Configuration

In order to properly configured the library there must be a header file in your project named atca_config.h at minimum this needs to contain defines for the hal and device types being used. Most integrations have an configuration mechanism for generating this file. See the atca_config.h.in template which is configured by CMake for Linux, MacOS, & Windows projects.

An example of the configuration:

/* Cryptoauthlib Configuration File */
#ifndef ATCA_CONFIG_H
#define ATCA_CONFIG_H

/* Include HALS */
#define ATCA_HAL_I2C

/* Included device support */
#define ATCA_ATECC608_SUPPORT

/* \brief How long to wait after an initial wake failure for the POST to
 *         complete.
 * If Power-on self test (POST) is enabled, the self test will run on waking
 * from sleep or during power-on, which delays the wake reply.
 */
#ifndef ATCA_POST_DELAY_MSEC
#define ATCA_POST_DELAY_MSEC 25
#endif

#endif // ATCA_CONFIG_H

There are two major compiler defines that affect the operation of the library.

ATCA_NO_POLL can be used to revert to a non-polling mechanism for device responses. Normally responses are polled for after sending a command, giving quicker response times. However, if ATCA_NO_POLL is defined, then the library will simply delay the max execution time of a command before reading the response.
ATCA_NO_HEAP can be used to remove the use of malloc/free from the main library. This can be helpful for smaller MCUs that don't have a heap implemented. If just using the basic API, then there shouldn't be any code changes required. The lower-level API will no longer use the new/delete functions and the init/release functions should be used directly.

Release notes

See Release Notes

Host Device Support

CryptoAuthLib will run on a variety of platforms from small micro-controllers to desktop host systems. The current list of hardware abstraction layer support includes:

Rich OS Hosts:

Linux Kit Protocol over HID USB
Linux I2C
Linux SPI
Windows Kit Protocol over HID USB

Microcontrollers:

Microchip AVR, SAM, & PIC families. See hal readme

If you have specific microcontrollers or Rich OS platforms you need support for, please contact us through the Microchip portal with your request.

CryptoAuthLib Architecture

Cryptoauthlib API documentation is at https://microchiptech.github.io/cryptoauthlib/

The library is structured to support portability to:

multiple hardware/microcontroller platforms
multiple environments including bare-metal, RTOS and Windows/Linux/MacOS
multiple chip communication protocols (I2C, SPI, and SWI)

All platform dependencies are contained within the HAL (hardware abstraction layer).

Directory Structure

lib - primary library source code
lib/atcacert - certificate data and i/o methods
lib/calib - the Basic Cryptoauth API
lib/crypto - Software crypto implementations external crypto libraries support (primarily SHA1 and SHA256)
lib/hal - hardware abstraction layer code for supporting specific platforms
lib/host - support functions for common host-side calculations
lib/jwt - json web token functions
test - Integration test and examples. See test/cmd-processor.c for main() implementation.

For production code, test directories should be excluded by not compiling it
into a project, so it is up to the developer to include or not as needed.  Test
code adds significant bulk to an application - it's not intended to be included
in production code.

Tests

There is a set of integration tests found in the test directory which will at least partially demonstrate the use of the objects. Some tests may depend upon a certain device being configured in a certain way and may not work for all devices or specific configurations of the device.

The test/cmd-processor.c file contains a main() function for running the tests. It implements a command-line interface. Typing help will bring up the list of commands available.

One first selects a device type, with one of the following commands:

204 (ATSHA204A)
108 (ATECC108A)
508 (ATECC508A)
608 (ATECC608A/B)

From there the following unit test sweets are available:

unit (test command builder functions)
basic (test basic API functions)
cio (test certification i/o functions)
cd (test certificate data functions)
util (test utility functions)
crypto (test software crypto functions)

Tests available depend on the lock level of the device. The unit tests won't lock the config or data zones automatically to allow retesting at desired lock levels. Therefore, some commands will need to be repeated after locking to exercise all available tests.

Starting from a blank device, the sequence of commands to exercise all unit tests is:

unit
basic
lockcfg
unit
basic
lockdata
unit
basic
cio
cd
util
crypto

Using CryptoAuthLib (Microchip CryptoAuth Library)

The best place to start is with the Microchip Trust Platform

Also application examples are included as part of the Harmony 3 framework and can be copied from the Harmony Content Manager or found with the Harmony 3 Framework Cryptoauthlib_apps

Incorporating CryptoAuthLib in a Linux project using USB HID devices

The Linux HID HAL files use the Linux udev development software package.

To install the udev development package under Ubuntu Linux, please type the following command at the terminal window:

sudo apt-get install libudev-dev

This adds the udev development development software package to the Ubuntu Linux installation.

The Linux HID HAL files also require a udev rule to be added to change the permissions of the USB HID Devices. Please add a new udev rule for the Microchip CryptoAuth USB devices.

cd /etc/udev/rules.d

sudo touch mchp-cryptoauth.rules

Edit the mchp-cryptoauth.rules file and add the following line to the file:

SUBSYSTEM=="hidraw", ATTRS{idVendor}=="03eb", ATTRS{idProduct}=="2312", MODE="0666"
